Product Overview: HR10-F to 6-Pin Housing Industrial Wire Harness (L=260mm)

Description:
This product is a customized wire harness designed specifically for industrial automation equipment, control systems, and precision machinery. It features a highly reliable HR10-F series aerospace-style connector (plug) on one end, interfacing with a 6-Pin (6P) housing socket on the other. With a standard length of 260 millimeters, it is engineered for stable transmission of control signals, sensor power, and data in harsh industrial environments, making it a critical component for ensuring efficient and reliable equipment operation.

Key Specifications:

• Connector A: HR10-F Series Plug (Male), renowned for its robust metal shell, excellent shielding, and secure locking mechanism.

• Connector B: 6-Pin (6P) Housing Socket (Female), typically matching the interface on the equipment side for a compact and stable connection.

• Cable Length: 260 mm (Other custom lengths available upon request).

• Cable Specification: High-quality cable with oil-resistant, abrasion-resistant, and flame-retardant (PVC or PUR) jacket. Internal conductors are made of fine-stranded tinned copper for superior conductivity and corrosion resistance.

• Contact Material: Gold-plated contacts to reduce resistance, prevent oxidation, and ensure clear signal transmission and long-term connection reliability.

Features & Benefits:

1. Exceptional Reliability & Durability: The HR10-F connector is known for outstanding resistance to shock, vibration, and accidental disconnection. Paired with high-quality cable, it withstands continuous stress and temperature variations in industrial settings.

2. Stable Signal Integrity: High-quality shielding and gold-plated contacts effectively minimize Electromagnetic Interference (EMI), ensuring accurate transmission of control signals and sensor data, thereby reducing equipment malfunctions.

3. Quick and Easy Installation: Standardized interfaces and foolproof keying design simplify equipment wiring and maintenance, significantly reducing installation time.

4. Superior Environmental Resistance: The cable offers excellent resistance to oil, chemicals, and flames, making it suitable for challenging applications such as robotics, CNC machinery, and production line equipment.

5. Customization Flexibility: In addition to the standard 260mm length, we support custom orders for different lengths, wire gauges, and color codes based on your specific application needs.

Typical Applications:

• Industrial Robots: Connecting controllers to joint servo motors and end-effectors (e.g., grippers, welding torches).

• CNC Machining Centers: Used for signal and power connections between the main control system and components like spindles, tool changers, and linear guides.

• Automated Production Lines: Interfacing sensors, pneumatic solenoid valves, and photoelectric sensors with control cabinets.

• Test & Measurement Equipment: Providing a stable and reliable signal transmission channel for precision instruments.

Quality Assurance:
This wire harness is manufactured in strict compliance with industrial standards and undergoes rigorous electrical testing, including continuity and insulation withstand voltage tests. We ensure every unit meets the highest demands for quality and reliability in industrial applications.

In summary, this 260mm HR10-F to 6-Pin Housing wire harness is an ideal connectivity solution for building stable and efficient industrial equipment systems. Its robust design and dependable performance provide strong assurance for the long-term, trouble-free operation of your machinery.
