XT60 Connector Solar Extension Cable Adapter for Power Stations

High-quality solar extension cable with XT60 connectors, engineered for efficient and safe power transfer between solar panels and portable power stations.

• Product Type: Solar extension cable

• Connector A: XT60 male plug

• Connector B: XT60 female plug

• Cable Length: 1m / 2m / 3m / 5m / customizable

• Conductor Material: Tinned copper

• Insulation Material: PVC / XLPE

• Outer Jacket: Black durable insulation

• Wire Gauge: 12 AWG / 14 AWG / 16 AWG optional

• Voltage Rating: DC 600V

• Current Capacity: Up to 30A

• Operating Temperature: -20°C to +85°C

• UV Resistance: Yes

• Waterproof Grade: IP65 (optional IP67)

• Flame Retardant: UL94V-0 compliant

• Durability: 5000+ mating cycles

• Flexibility: Bend radius ≥30mm

• Mechanical Strength: Anti-pull and vibration-resistant

• Contact Material: Gold-plated copper

• Contact Resistance: ≤1mΩ

• Insulation Resistance: ≥1000MΩ

• Dielectric Strength: 2.5kV DC/min

• Connector Housing: Heat-resistant nylon

• Color: Black cable with yellow XT60 connector

• Certifications: CE, RoHS

• Environmental Resistance: Moisture, UV, and dust resistant

• Safety Standard: IEC/EN compliant

• Application 1: Solar panels to power station

• Application 2: Portable energy storage

• Application 3: RV solar systems

• Application 4: Camping and outdoor power

• Application 5: Emergency backup systems

• Packaging: Individual polybag or bulk carton

• OEM/ODM: Supported

• MOQ: Flexible order quantity

• Installation: Plug and play

• Maintenance: Easy to clean and store

• Service Life: 5+ years

• Weight: Lightweight and portable

• Warranty: 12 months

• Customization: Length, gauge, and connector options available
