The Customized Wiring Harnesses are designed to meet diverse industry requirements, including aerospace, automotive, medical, and telecommunications. Engineered with copper conductors and advanced insulation, they ensure safety, durability, and reliable connectivity. Below are the detailed attributes:
Conductor Material: Copper
Application: Aerospace, Automotive, Medicine, Telecommunications, Electronics
Insulation Material: PVC/XLPE/PTFE (Customizable)
Connector Type: Customizable (Molex, JST, Deutsch, Aviation, etc.)
Wire Gauge: 18AWG - 28AWG
Voltage Rating: 300V - 600V
Current Rating: 3A - 20A
Temperature Resistance: -40°C to +200°C
Flame Retardant: UL94V-0
Waterproof Rating: IP65/IP67/IP68 (Optional)
Shielding: Braided Copper Shield / Aluminum Foil Shield
Durability: 5000+ Mating Cycles
Flexibility: High Flex Life
Mechanical Strength: High Tensile Strength
Signal Type: Power & Data Transmission
Contact Resistance: ≤10 mΩ
Insulation Resistance: ≥1000 MΩ
Connector Housing: Plastic/Metal Options
Connector Gender: Male/Female
Connector Locking System: Screw Lock / Snap Lock
Wire Protection: Braided Sleeve, Heat Shrink Tubing
Environmental Resistance: Oil, UV, Chemical, Corrosion Resistant
Weight: Lightweight Design
Customization: Length, Color, Connector Type
Standards: RoHS, CE, UL, ISO, MIL-Spec Certified
Operating Environment: Aerospace, Automotive, Industrial, Medical
Performance: Stable Signal Integrity
Shock Resistance: High Vibration and Shockproof
Thermal Resistance: Excellent Heat Endurance
Safety: Insulated, Flame Retardant, Shockproof
Packaging: Anti-static Bag / Customized
Quality Control: 100% Electrical Testing
Production Lead Time: 7-20 days
MOQ: 100 Pieces
Service Life: Long-term Reliability
Compatibility: Aerospace, Automotive, Medical, Telecom Systems
Maintenance: Easy Replacement and Repair
Environmental Protection: Eco-friendly Materials
Assembly Method: Crimped / Hand-soldered
Resistance: Extreme Temperature and Environmental Resistance
